Wall Mount Bathroom Shower Panel System Installation

All Shower Panels are Brand NEW! Comes Complete Ready to Install with Easy Installation Instructions

BathSelect shower panel system will not only enhance the look of your shower space, it will transform your everyday shower or bath to a uniquely satisfying shower. The contemporary design of the shower panel will compliment most styles of the bathroom or wet room. Those pulsating shower massage comes with an adjustable shower head, additional handset, body jets and chrome thermostatic controls.

Many homeowners are choosing bathroom shower panels because it accentuates the bathroom with a stylish decor and is convenient to maintain. Shower panels are the best economical option to enhance your bathroom.

BathSelect shower panels come in many styles!

Safety is paramount and because the supply pipes to the shower are enclosed within an aluminium casing, they are protected from accidental or intentional damage, while users are protected from the high surface temperature of the hot water pipe. The panel is durable so that the shower unit can operate over an extended lifespan, providing reliability and value for money.

All of the shower panels feature water saving fittings, to ensure that an optimized flow of water is maintained while avoiding unnecessary wastage of energy and water. Wall mount shower panels are easy to install and the reciprocal of this means that at the end of their life, they can also be easily uninstalled and materials recovered for recycling. Maintenance of shower panels is made easy due to the accessibility of the isolating servicing valves and ease of access to the internal thermostatic valve, strainers and water supplies.

Ready to pamper yourself yet? If so, installing a Shower Panel is no more difficult than replacing your pre-existing shower arrangement with a new one. If you’re starting fresh with no existing shower, consult a plumbing expert prior to plugging one into your shower wall.

Installation wall mount shower panels

Install ½-inch IPS nipples for the hot and cold water supplies. The nipples should extend ? of an inch beyond the wall. The hot water supply is on the left, and the cold on the right. Install the wall surface material. Ensure the wall is watertight before installing the panel by applying a waterproof sealant, such as Teflon tape or plumber’s putty.

Install the elbows included with the panel and point them downwards. The elbow should extend no more than 1 ¼ inches from the surface of the wall. With a helper holding the panel in place, mark the positions of the screw holes and drill the holes with a 6 mm bit suitable for the wall surface.

Drop anchor Install the anchors and seal the wall with a waterproof sealant. While holding the panel against the wall, install the provided grey plastic insert and the top screw into the anchor.

Make your connections Install the center and bottom screws and washers. Connect the supply hoses to the hot and cold supply elbows and the inlet ports on the valve. Turn the water on at the main. Push the diverter stem up to turn the water on to the panel, and check the connections for leaks. When the connections are watertight, push the diverter stem down to cut the water.

Just a few easy installments

Install the side seals on the front cover, trim off any excess and push the front cover into place. Install the diverter sleeve. Make sure the indexing mark on the thermostatic mixer sleeve is at the 12 o’clock position. Install the thermostatic mixer handle, and tighten the handle screw with a flat-head screwdriver.

To install the diverter handle, tighten the set screw with a 4 mm Allen wrench. Place a black rubber washer in one end of the hand shower hose, and fasten the hose to the hand shower outlet port. Place the screen washer in the other end of the hose, and screw this end of the hose to the hand shower. Place the hand shower in the holder.

Adjust the Slider

You can make the slider easier or harder to move by using a 2 ½ mm Allen wrench. Turn the water on to the handshower, and turn the thermostatic mixer handle until the output water measures 100 degrees on a thermometer, then cut the water. Turning the handle clockwise makes the water cooler, counter-clockwise makes the water warmer.

Loosen the thermostatic mixer handle screw, and remove the handle. Replace the handle so that the safety stop override button is at the 12 o’clock position.
