Step by Step Simple Shower Panel Installation Guide

(updated Jun 7, 2023)

First of all thank you for buying a shower panel from BathSelect. We are happy to for you to have a SPA like experience in the bathroom of your home. This step by step shower panel installation guide will help you in a easier way.

Note – Shower panel installation requires some experience of plumbing. If you are not familiar with it, please ask help from a professional plumber.

Shower Panel Ready to install in just few simple steps

Installing shower panel is not a pain. As a matter of fact our shower panel installation is so simple and can be done in few easy steps. The shower panel or shower tower are designed for both bathroom upgrade (without the need to destroy your wall) and also can be installed in new construction.

All our shower towers are pre plumed and are ready for installation. Our selection of shower panels comes with an exceptionally sophisticated look made of stainless steel. It comes with body pulsating spray jets along with a rainfall shower head, some come with digital temperature display and most of our selections comes with thermostatic anti scalding shower valve to prevent scalding. All our selections of shower panels give you a better shower experience than just using a conventional shower. While also saving you money on costly installations.

Our pulsating massage shower panel body jets provide you the benefits of a massage and acupressure applying pressure to specific “pressure points” on the body to improve the flow of energy. You can always check our latest sale on shower towers with free delivery.

Check our Shower Panel Installation general diagram and illustrations (which is not meant for a specific shower model). As every model has its complete, easy and simple shower panel installation instructions that comes with it.

Shower Panel System comes with:

1. 1. Hand shower.
   2. Shower head.
   3. Panel frame.
   4. Shelf.
   5. Adjustable jets.
   6. Diverter, Mixer and Thermostatic a
   7. Connection base to handheld shower hose.
   8. Tub spout.
   9. Shower head hose.
   10. Mounting bar.
   11. Built in mixer flow diverter and thermostatic anti scalding device.
   12.  Hoses connected to the different functions.
   13. Standard US 1/2 ” plumbing hot water hose (red).
   14. Standard US 1/2 ” plumbing cold water hose (blue).

Shower Panel Installation Instructions

The Installation of Shower Panels is simple and easy;

Remove currently installed fixtures from bath shower system (hot and cold water knob(s)). Install two installation brackets onto the wall (Panel installs at desired height / all hardware is included). Connect the hot (Red) and cold (Blue) water hook-ups (All plumbing is standard US 1/2″). Hang the shower system on the previously installed brackets.

Test shower system to ensure the product is working properly.Caulk around the edges of the unit> (This is only required on some models). Enjoy the relaxing experience the Massage Shower Panel has to offer!

Total Estimated Installation Time: 30 Minutes to 1 Hour

This cutting-edge panel boasts a powerful rainfall showerhead, invigorating massage jets, and easy-to-use controls for a personalized journey to relaxation. Its sleek design and durable construction add a touch of elegance to your bathroom, while simple installation ensures a hassle-free upgrade. Immerse yourself in the ultimate spa-like escape and redefine your daily routine with the LUNA Shower Panel today.

BathSelect Shower Tower in a striking brushed nickel finish. What sets this shower tower apart is its seamless fusion of modern design and exceptional functionality. The brushed nickel finish not only exudes timeless elegance but also offers exceptional durability and resistance to tarnish, ensuring a long-lasting pristine look. With an array of customizable features including rainfall showerhead, body jets, and handheld shower wand, all operated through an intuitive control panel, this shower tower offers a spa-like experience tailored to your desires.

.

Shower Panel More Technical details

1.2 GPM Delivered per body spray under 45 PSI Efficient massage and low water consumption. Standard half inch plumbing, factory pre-plumbed Requires only 40psi to run. The minimum pressure required is 29 psi and maximum pressure required 72.7.The minimum flow rate for both cold and hot water is 3.70 gpm

Nothing to recess (avoids most risk of water damage).Fast and convenient access for easy maintenance. With the ever growing support of North American Plumbing Codes requiring temperature protection in the shower, most massage shower panels come with built-in thermostatic mixer which provides stable mixed water temperature, that works as an anti-scalding device in the showers.

Please note: If you have enough water pressure to adequately operate a handheld shower, you will not experience water issues with any of our shower panels. If you’re absolutely sure you have low pressure in your house, you may have problems any shower panel will not solve.

BathSelect Video Shower Panels

BathSelect.com Bath Related Technical Installation Links

• BathSelect Shower Panels
• Bathroom Faucets
• Shower Sets

At BathSelect you are guaranteed to find best combination of Quality & Value for a wide selection of quality bathroom Shower Panels, Faucets, Shower Massage Panels, Led Showers, Sauna, Massage Head Showers, Whirlpool, Sensor Faucets, Shower Sets and more.

Call our Sales Dept. 24/7 at 1-800-500- 9895

Buy Best Massage Shower Wall Panels System

The ultimate contemporary Massage Bathroom Shower Panels for a joyful luxurious shower experience! Stylish yet functional shower panels at BathSelect will enhance your overall everyday routine. Useful thermostatic pulsating massage shower panels will provide you with the utmost showering experience. BathSelect contemporary massage shower panels allow you to change your existing bathroom shower enclosure into a tastefully designed and functional shower.

Bathselect provides Best shower panel System, shower massage panel, shower wall panels, bathroom shower panels, bathroom shower wall panels, multi head shower panels, top rated shower panels, best shower panels with jets, bathroom shower jet systems, decorative shower panels, tub shower wall panels, thermostatic shower panel, rainfall shower panel, body spray shower panels, bronze shower panel, oil rubbed bronze shower panel, brushed nickel shower panel, black shower wall panel, and many more.

Choose from many styles and functions with features that you would never imagine. At BathSelect, you will find that all of our shower panels come complete with a shower head, handheld shower, massage body jets, built-in thermostatic device, built-in diverter valve, flow control, etc. We know you’ll enjoy choosing and using your ultimate shower experience!

Turn Your Bathroom Into A SPA … With BathSelect Sensational Shower Wall Panels:

BathSelect’s Shower panels allow you to turn your home bathroom into a luxury spa experience easily. With the wide variety of options, you can find decor or enhance your bathroom as per your liking. Shower Massage Panel with rainfall shower head can make your showering experience even more spa-like. On the other hand, a shower panel with handheld shower head gives you the freedom to move the shower spray anywhere in your bathroom. Enjoy a spa quality massage in the comfort of your home bathroom with top quality shower panels from BathSelect.

Our Pulsating Massage Shower Wall Panels Come With Features Like:

• Adjustable hand held shower
• Adjustable body massage sprays
• Large overhead shower
• Individual water controls
• An anti-scalding device, and much more!

FontanaShowers™ feature unique elements of design like shelves, mirrors and accessories; hence your bathroom shower not only gets a beautiful facelift but also becomes more functional. Installation is easy on all BathSelect shower panels with just a hot and cold water connection and hassle-free mounting with wall-attached brackets.

FontanaShowers™ shower panels will turn your ordinary shower into a home spa. BathSelect massage shower panels come loaded with some extra features including rainfall shower heads, massaging shower heads, Shower head wall panels, Jetted adjustable body nozzles, Jetted shower panel, digital display complete bathroom shower panel systems,luxury shower panel, and more, thus in less than 30 minutes, you can transfer your shower into a luxurious showering experience.

Shower panels often incorporate a range of advanced functions and features to enhance the showering experience. Here are some common functions in luxury shower panels:

1. Multiple Showerheads: Some may feature multiple showerheads, allowing for a combination of rainfall showerheads, handheld showerheads, or even body jets. This provides a variety of water streams and angles, creating a spa-like shower experience.
2. Thermostatic Temperature Control: These typically have precise thermostatic temperature control, enabling users to set and maintain their desired water temperature. This ensures a comfortable and consistent shower experience without sudden temperature fluctuations.
3. Water Pressure Control: Shower panels often offer adjustable water pressure settings, allowing users to customize the strength of the water flow to their preference. This feature ensures a personalized and invigorating shower experience.
4. Digital Controls: Some luxury ones come with digital controls, allowing users to conveniently adjust various settings such as water temperature, water pressure, and showerhead selection. These digital interfaces often feature touchscreens or buttons for easy operation.
5. LED Lighting: LED lighting features can be incorporated into luxury shower panels to create ambient lighting or chromotherapy effects. These LED lights can provide soothing colors and enhance the overall aesthetic appeal of the shower tower.
6. Integrated Audio System: Some high-end tower may include integrated audio systems, allowing users to listen to their favorite music or podcasts while showering. These audio systems are often Bluetooth-enabled, providing seamless connectivity with mobile devices.
7. Steam Functionality: Certain ones may have built-in steam generators, allowing users to enjoy a steam shower experience. This feature can provide relaxation, help relieve muscle tension, and promote a spa-like ambiance.
8. Built-in Shelving or Storage: Luxury ones may include built-in shelves or storage compartments for convenient storage of shower essentials such as shampoos, conditioners, and soaps. This adds functionality and organization to the shower space.

It’s worth noting that the specific functions and features of these shower panels can vary depending on the brand and model. When considering a purchasing one, it’s advisable to research different options to find a product that aligns with your preferences and desired showering experience.

Rain Style Pulsating Massage Shower Panel Installation Instructions

Blue Tempered Glass Multi-Function Massage Jets Rainfall Shower Panel Installation Instructions

In this article we covered the following:

Shower Towers

They have become increasingly popular in modern bathroom designs. There are several reasons why some people might find shower towers to be better for installations compared to other basic or regular showers:

1. All-in-One Design: Shower towers usually come as a single unit that integrates various shower functions like overhead rainfall showers, handheld sprayers, body jets, and sometimes even a tub spout. This integration can simplify the installation process as everything is pre-configured.
2. Space Efficiency: Because of their sleek and vertical design, shower towers can be a good fit for bathrooms with limited space. They often require less horizontal plumbing compared to separate fixtures.
3. Easy to Upgrade: For homeowners looking to upgrade from a simple shower setup without extensive remodeling, a shower tower can be a more straightforward option. The panel can be installed over existing plumbing with minimal adjustments.
4. Modern Aesthetics: Shower towers typically have a contemporary look and can instantly modernize a bathroom’s appearance. Their cohesive design can also lead to a more streamlined and neat look compared to individual fixtures.
5. Consistent Design and Finish: Since everything is integrated into one panel, there’s no need to worry about mismatched finishes or styles, which can sometimes be a concern when selecting individual fixtures.
6. Reduced Plumbing Complexity: With traditional shower systems, each fixture (like separate body sprays or rain showerheads) may require its own plumbing lines and controls. With a shower tower, the internal plumbing is already integrated into the panel, potentially reducing the complexity and time required for installation.
7. Integrated Controls: Many shower towers come with thermostatic controls, diverter valves, and other features integrated into the panel. This can offer a more intuitive and consolidated user experience.

However, it’s essential to note that while there are benefits to shower towers, they may not be for everyone. Some potential drawbacks include:

• Limited Customization: Since everything comes pre-configured, there’s less flexibility to customize specific components to personal preferences.
• Potential Repair Challenges: If one component of the shower tower malfunctions, it might require more in-depth work or the replacement of the entire unit.

In conclusion, while shower towers offer several installation and design benefits, the decision between a shower tower and a traditional shower system can only be achieved based on weighing the pros and cons of the above variable.

Without the need for extensive construction work. Our shower panel installation is designed to be hassle-free and can be completed in just a few simple steps.

BathSelect shower panels, also known as shower towers, are specifically engineered for bathroom upgrades without requiring any wall demolition. They are equally suitable for installation in new construction projects.
